Cement Compression & Flexure Testing Machine
  • This Compression and Flexure Testing Machine conforms to GB/T 17671, EN 196, ISO 679, ASTM C 109 and EN ISO7500-1 etc.


    • Load frame of cast steel structure with high stiffness

    • Compact structure with oil source at the bottom of load frame to save installation space

    • Compression test and flexure test can be done separately on one testing machine with high test efficiency

    • Safety limitation switch to protect operators in the test process

    • Home Power 220V, Single Phase: Optimize the electrical structure by adopting integrated circuits to realize machine with single phase home power supply instead of industrial 3-phase power supply, which makes performance more stable and prevents high-voltage power leakage problem for more safe purpose.
    • Max. Compression load: 300/200kN

    • Loading range: 3-300kN; 2-200kN

    • Constant loading speed: 0-3kN/s

    • Piston stroke: 20mm

    • Max. Flexure load: 10kN

    • Loading range: 0.1-10kN

    • Indicating value relative error: ±1%

    • Indicating value repeatability error: 1%

    • Zero-return relative error: ±0.1%

    • Load resolution: 0.5%

    • Load cell accuracy: 0.1%

    • Max. Oil pressure: 20Mpa

    • Platen size: dia. 160mm

    • Piston stroke: 20mm

    • Power supply: 220V, 1phase, 50Hz, 750W

    • Dimension: 1100x400x1350mm

    • Weight: 250kg

    • Flexure fixture for 40x40x160mm specimen


    Cement Compression & Flexure Testing Machine.jpg


Previous:There's no more content
Model: CST-300/200
Description:
This Compression and Flexure Testing Machine is mainly designed for compression and bending tests of cement & mortar specimens. The Compression and Flexure Tester for Cement can finish compression or flexure tests automatically by one-key action. Computer & software are also adopted to make the operation even easier. With new design and advanced technology, the series of Compression and Flexure Testing Machine have more advantages in appearance, operation & applications. The Compression and Flexure Tester for Cement is an ideal tester for quality control at industrial & mineral enterprises, teaching in high schools, and technology researching at scientific institutes.
